HU-226-3-VDC-17 Mamac Systems Humidity Sensor HU-226-2/3-VDC-17

HU-226-3-VDC-17 - Humidity Sensor

Model: HU-226-3-VDC-17

Range: 0-100% RH

Supply Voltage: 12-35 VAC / 12-40 VDC

Output: 0-5 VDC/0-10 VDC field selectable

Temperature Sensor: 20,000 ohm Thermistor

Product Category: Humidity Sensors

Brand: Mamac Systems / Honeywell

Condition: Lotted New

Stock: Subject to availability

Price: Available on request

Product Location: Brands > Mamac Systems > HU-226-3-VDC-17

HU-226-3-VDC-17 Humidity Sensor

The HU‑226 is an extremely fast, stable and accurate humidity/temp sensor designed for harsh environments. The polymer humidity capacitance sensor is protected with an ePTFE (expanded Teflon) filter media. The Teflon protected cross‑linked capacitive humidity sensor is not affected by prolonged exposure to condensing humidity, harsh environments, contaminants, fog or other extreme environmental conditions. Each unit is individually calibrated in an environmental test chamber to meet or exceed NIST traceable (‑+2%) or (‑3%) accuracies. The HU‑226 is temperature compensated for ‑30 F (‑35 C) to +130 F (55 C) operation with negligible error. Field selectable outputs, and fully temperature compensated NIST traceable accuracy, non‑interacting zero and span adjustments, NEMA‑4 (IP‑65) steel enclosure with external mounting bracket and short circuit and reverse polarity protected output are some of the features which make the HU‑226 the industry's highest performance, most reliable humidity/temp sensor.
